SS 304 / SS 316 Y Type Flush Bottom Valve – Flanged ASA 150#, Outside Opening
A Y type flush bottom valve mounts on the bottom nozzle of a reactor and drains the vessel completely.
Body: SS 304 / SS 316
Design: Y type flush bottom (tank bottom) valve, outside opening (piston moves away from tank)
Ends: Flanged ends to ASA 150#
Operation: Hand wheel
Sizes: 25 × 25 mm to 150 × 150 mm
Price per piece · GST extra · Ex-works Ahmedabad
Price range: ₹16,100.00 through ₹96,600.00 + GST
Description
SS 304 / SS 316 Y Type Flush Bottom Valve – Flanged ASA 150#, Outside Opening – Specifications & Price
The SS 304 / SS 316 Y Type Flush Bottom Valve – Flanged ASA 150#, Outside Opening is made by Universal Valves Pvt. Ltd., Ahmedabad, part of the Universal Group, which has manufactured industrial valves since 1972. A Y type flush bottom valve mounts on the bottom nozzle of a reactor and drains the vessel completely. In the outside opening design, the piston moves away from the tank to open.
Stainless steel gives excellent corrosion resistance and hygiene. SS 202 is an economical grade for general service, SS 304 is the all-round grade, and SS 316 adds molybdenum for chlorides and aggressive chemicals.
Available in sizes 25 × 25 mm to 150 × 150 mm. Choose body material from SS 304. Select your size and options above to see the price per piece.
Key Features
- Flush closing – no dead space in vessel
- Y pattern for smooth, complete drainage
- Outside opening (inside opening on request)
- Inlet × outlet sizes to suit vessel nozzles
Technical Specifications
| Design | Y type flush bottom (tank bottom) valve, outside opening (piston moves away from tank) |
|---|---|
| Body | SS 304 / SS 316 |
| Ends | Flanged ends to ASA 150# |
| Size Format | Inlet × Outlet (mm) |
| Operation | Hand wheel |
| Size Range | 25 × 25 mm to 150 × 150 mm |
| Body Material Options | SS 304 |
| Testing | Hydrostatic shell & seat test, generally to API 598 |
| Manufacturer | Universal Valves Pvt. Ltd., Changodar, Ahmedabad, Gujarat, India |
Applications
Typical uses include chemical and pharmaceutical reactors, glass-lined and SS vessels. Stainless Steel construction is widely used in chemical, pharmaceutical, food, dairy, water and utility services.
Options & Notes
- Inside-opening flush bottom valves are also available – rates on request.
Pricing & Ordering
- Prices are per piece in Indian Rupees, ex-works Ahmedabad.
- GST extra: 18% IGST, or 9% CGST + 9% SGST within Gujarat.
- Packing & forwarding: 1.5% extra.
- Third-party inspection, if required: 5% extra.
- Test certificates and material test certificates are available on request.
For special sizes, materials, pressure ratings, drilling standards or actuation, contact our sales team – custom valves are made to your drawing or specification.
Additional information
| Size | 25 × 25 mm, 40 × 25 mm, 40 × 40 mm, 50 × 25 mm, 50 × 40 mm, 50 × 50 mm, 65 × 40 mm, 65 × 50 mm, 65 × 65 mm, 80 × 50 mm, 80 × 65 mm, 80 × 80 mm, 100 × 50 mm, 100 × 80 mm, 100 × 100 mm, 150 × 100 mm, 150 × 150 mm |
|---|---|
| Body Material | SS 304 |
