Product Overview

The P.P. Diaphragm Valve – Screwed / Flanged End is made by Universal Valves Pvt. Ltd., Ahmedabad, part of the Universal Group, which has manufactured industrial valves since 1972. A diaphragm valve closes by pressing a flexible diaphragm onto a weir. The diaphragm isolates the operating mechanism from the fluid, so it handles corrosive, abrasive and hygienic media without leakage to atmosphere.

Polypropylene (PP) is a lightweight thermoplastic with excellent resistance to many acids, alkalis and salts. It is ideal for corrosive liquids at moderate temperatures.

This item is supplied to order. Sizes, pressure ratings, end connections and trim options are confirmed against your requirement. Fill in the quote form below, or call or email us, and our team will send you the price and delivery time.

Key Features

• Diaphragm isolates bonnet from fluid – no gland leakage
• Smooth flow path with no pockets
• Handles corrosive, abrasive and slurry media
• Diaphragm can be replaced in-line

Technical Specifications

Applications

Typical uses include chemical, water treatment, DM plants, effluent, food and pharmaceutical lines. Polypropylene construction is widely used in chemical dosing, water treatment, effluent, electroplating and acid handling.

Pricing & Ordering

• Price on request – use the quote form below, or call us with size, quantity and service conditions.
• GST extra: 18% IGST, or 9% CGST + 9% SGST within Gujarat.
• Packing & forwarding: 1.5% extra.
• Third-party inspection, if required: 5% extra.
• Test certificates and material test certificates are available on request.

For special sizes, materials, pressure ratings, drilling standards or actuation, contact our sales team – custom valves are made to your drawing or specification.

Image shown is an illustration. Actual product design and finish may vary.
