Product Overview

The Forged Carbon Steel A-105 Piston Valve 800# – Screwed End is made by Universal Valves Pvt. Ltd., Ahmedabad, part of the Universal Group, which has manufactured industrial valves since 1972. A piston valve isolates flow with a stainless steel piston sliding between two resilient sealing rings instead of a disc on a seat. There is no metal-to-metal seating, so there is little wear and the valve stays leak-tight for years on steam service.

Forged bodies (ASTM A105 carbon steel, A182 F304/F316 stainless or F11/F22 alloy steel) are dense and free from casting defects. This makes them the preferred choice for small-bore, high-pressure and high-temperature lines.

Available in sizes 15 mm to 40 mm. Select your size and options above to see the price per piece.

Key Features

• Piston & sealing ring design – no seat wear
• Leak-proof gland and seat on steam service
• Sealing rings are replaceable in-line
• Minimal maintenance

Technical Specifications

Applications

Typical uses include steam and condensate lines, boilers, thermic fluid and hot water. Forged Steel construction is widely used in refineries, power plants, petrochemicals, steam and high pressure process lines.

Pricing & Ordering

• Prices are per piece in Indian Rupees, ex-works Ahmedabad.
• GST extra: 18% IGST, or 9% CGST + 9% SGST within Gujarat.
• Packing & forwarding: 1.5% extra.
• Third-party inspection, if required: 5% extra.
• Test certificates and material test certificates are available on request.

For special sizes, materials, pressure ratings, drilling standards or actuation, contact our sales team – custom valves are made to your drawing or specification.
